Daemo DRP235 Rotating Pulveriser
Dual Motor provides a maximum rotation torque
360 Degree Hydraulic Rotation allows the right positioning to work
Reversed Cylinder protects the cylinder rod from debris
Speed-up Valve accelerates working speed
Cutting Blades are 4-edge usable and interchangeable
Replaceable Teeth are bolt-on type for fast replacement
Suitable Excavator 22-30 ton
Weight 2,200kg
Jaw opening 800mm
Jaw depth 838mm
Overall length 2,177mm
Blade length 300mm
Upper jaw width 313mm
Lower jaw width 492mm
Crushing Force (Mid) 147 kN
Crushing Force (Tip) 110 kN
Min. cycle time (open/close) 1.8 / 2.1 sec
Operating pressure 350 kgf/cm2
Oil flow rate 220-280 LPM
Setting Pressure 120 kgf/cm2
2 Motor oil flow rate 32-40 LPM
Revolving speed 8-10 RPM
