Dealer Comments
New Striker JQ1170 Jaw Crusher
In stock Melbourne
HOPPER
7 / 10 m3 Capacity
POWER PACK
Caterpillar 265kw Tier 111 Diesel Engine Fuel Tank 640 litre Hydraulic Tank 620 litre
CRUSHER
1,070mm x 740mm (42 x 29)
CONVEYORS
Forward Product Conveyor Width 1,200mm (311), Discharge Height 3,300mm (1010) Side Conveyor (Optional) Width 600mm (2), Discharge Height (adjustable) 2,100mm (611)
PERFORMANCE
Capacity up to 325 T/Hour Gap setting 50mm 175mm (2 6.9)
CONTROL
Full Remote Control
TRACKS
Length 3,800mm (126) Width 400mm (14)
OPERATING DIMENSIONS
Length 14,931mm (49) Width 4,066mm (134) Height 4,316mm (142) Weight 48T (105,822lbs)
TRANSPORT DIMENSIONS
Length 15,139mm (498) Width 3,184mm (105) Height 3,841mm (127) *HIGHER AND WIDER KIT
makes unit 400mm wider and 250mm higher for operation and transport
OPTIONS (Available, not included)
Dust Suppression, Canvas Covers, Water Pump, Side Conveyor Over-band Magnet
WARRANTY
1-year/2000hr Full Factory Warranty. 5-year Frame Warranty
MANUALS
2 operation and parts manuals are included with every machine.
COMMISSIONING
Includes 1 full day commissioning by experienced representative.
RISK ASSESSMENT
All new machines come with a risk assessment upon delivery.
TRANSPORT
Unless otherwise quoted, transport is from the nearest port or branch depending on the location. Additional charges will apply for transport to customer site.
