Hidromek Hmk460mg

NEW Hidromek HMK460MG Motor Grader

GENERAL
Operating Weight 17,700 kg.
Articulated Frame 29 degrees.
3,710mm mould board (12).
Rear ripper scarifier
Tyres 14.00 24 12PR.

ENGINE & RELATED ITEMS
Mitsubishi 6D24-T engine, 4 Cycle, Turbocharged,
Direct Injection, Water Cooled Diesel Engine.
116 -138kw (155-185hp) @ 2000 rpm
925 Nm Torque @ 1200 rpm

SPECIAL ARRANGEMENTS
Compatible with USA EPA Tier 1 and European.

DRIVES & BRAKES
Powershift planetary gear-hydraulically actuated transmission with 8 Speeds.
Double reduction spiral bevel and planetary gears.
Operator controlled hydraulic differential lock.
Front wheel lean 20 degrees left and right.
Front axle oscillation 15 degrees left and right.
Air actuated, multi disc oil cooled brakes actuate all 4 rear wheels.

HYDRAULIC SYSTEM
Closed centre load-sensing hydraulic system.
Variable displacement piston type pump, 174 L/min.
Pilot pressure-controlled type.

CONTROL
Full hydraulic front wheel steering with Hand Metering.
Industry Standard Soft Touch, short stroke levers providing precise implement control.
Steering wheel and Shift Lever require little effort to adjust ensuring smooth operation.
8 Fwd. 8 Rev gears
Blade slip clutch

SAFETY EQUIPMENT
Factory ROPS certified cab.
Hand rails.
Anti-slip plates.
Safety glass windows.
Wide range visibility

OPERATOR ENVIRONMENT
Air-conditioned cabin.
Air Suspension seat with heater.
Tilting Steering Column.

OTHER STANDARD EQUIPMENT
Travel Alarm.
Tool Kit.

FACTORY OPTIONS (Not Included):
Front Counterweight.
Front Blade
14.00 x 24 Tyres (17.5 x 25 Optional)

ELECTRICAL SYSTEM
Alternator 50 Amp,
Batteries 24 Volt 150 Ah.
Starter motor 24V

MATERIALS
Comes with Delivery kit, Operators manual, Parts manual, Risk Assessment.


WARRANTY
3 years / 6000 hours or whichever occurs first.

DELIVERY
Pricing does not include machine delivery unless otherwise quoted and shown within this submission. Machine transport is to be calculated from the existing machine location in Australia or the nearest port / branch if not already in Australia.
