Striker CQ400

NEW Striker CQ400 Cone Crusher

FEEDER
5 / 7 m3 Capacity fitted with Metal Detector.

POWER PACK
Caterpillar C13 328kw Tier 3 ACERT Diesel Engine
Fuel Tank 840 litre, Hydraulic Tank 600 litre
Radiator Blast Guards
Load Sensing Hydraulic System

CRUSHER
1,200mm (47) Medium Liner fitted as standard

CONVEYORS
Forward Product Conveyor Width 1,200mm, Discharge Height 3,310mm
Dust Spray bars fitted to Forward Product Conveyor, Water Manifold fitted
Stacker Outlet

PERFORMANCE
Capacity up to 400 T/Hour Gap setting 10mm 50mm

CONTROL
Full Radio Remote Control, Striker Optimax engine and feeder controller

TRACKS
Length 3,800mm (126) Width 400mm (14)

OPERATING DIMENSIONS
Length 15,705mm Width 3,940mm, Height 4,790mm

TRANSPORT DIMENSIONS
Length 16,745mm Width 3,260mm Height 4,166mm
Weight 47,000kg

SPECIFIC OPTIONS FOR THIS MACHINE
Hardox Hopper Liners, High & Wide Track Kit, Zero-set on Cone, Nip Point Guarding, E-Stops, Central Greasing Banks, Warning Siren for tracking and startup, Control Panel Pressuriser, Air Intake Snorkel

WARRANTY
1-year/2000hr Full Factory Warranty. 5-year Frame Warranty

MANUALS
2 operation and parts manuals are included with every machine.

COMMISSIONING
Includes 1 full day commissioning by experienced representative.

RISK ASSESSMENT
All new machines come with a risk assessment upon delivery.

Similar Models:
Anaconda C12, Powerscreen 1300 Maxtrak, Metso LT300HP, Sandvik QH441, Kleeman MCO 11 PRO, McCloskey C4, Finlay C-1550
Large Cone Crusher, 400HP Cone, Secondary Tertiary Cone Crusher
