2024 XCMG Xg0807acw

New XCMG XC0807ACW Scissor Lift
YOM: 2024
Sell price $16,500 + GST
Located in , Tasmania

KEY PERFORMANCE SPECS
Battery: 24V / 280Ah
Battery Model: 3-EV-225
Tyre Specification: 323 x 100mm non-marking solid
Total Machine Weight: 1580kg
Overall Length (No Ladder): 1900mm (1680mm)
Overall Width: 810mm
Overall Height (Platform Folded): 2010mm (1874mm)
Length x Width Working Platform: 1670mm x 740mm
Length of Extension Platform: 900mm
Wheelbase: 1360mm
Max Working Height: 7.8m
Max Platform Height: 5.8m
Load Capacity: 230kg
Load Capacity of Extended Platform: 115kg
Max Occupant Capacity: 2
Minimum Ground Clearance (Pot Hole Protector – raised / lowered): 70mm / 20mm
Minimum Turning Radius (Inner / Outer Wheel): 0m / 1.75m
Lifting Motor: 3.3 kW / 4.4 hp
Lifting / Descending Duration of Platform: 15-25s / 25-35s
Maximum Travel Speed (Low Level): 4.5 km/h
Maximum Travel Speed (High Level): 0.8 km/h
Maximum Gradeability: 25%
Maximum Inclination (Side / Forward and Backward): 1.5 / 3 Degrees
